Specifications

With the Wired Auxiliary Output control, the intelligence of the CERV can be expanded to other devices in your home. The CERV comes with one built in 277VAC, 15A capable dry contact relay, and another six 24VAC or dry contact (user selectable) 0.5A can be added with the I/O Expansion Board.

Available functions for Wired Auxiliary Outputs:

Heat

Cool

Vent

Humidity Removal

Humidity Addition

Heat Exchanger

Zone Damper

Fan Interlock

With the Wired Auxiliary Input control, the CERV can be remotely triggered to heat, cool, ventilate, etc. by other devices in your home. The CERV comes with one built in dry contact sense or 24VAC sense (user selectable, and another three can be added with the I/O Expansion Board.

Available functions for Wired Auxiliary Inputs:

Heat

Cool

Vent

Recirculation

Halt Operation

The CERV comes standard with Enocean Wireless Communication, a low power protocol for interaction with local devices. Up to 18 devices can be paired with the CERV, from wireless battery free ventilation switches and remote sensors to Active Circuit Transmitters (expanding Auxiliary Inputs) and Wireless Relays (expanding Auxiliary Outputs).

Available Wireless Devices:

Ventilation Switch

Active Circuit Transmitter

Remote Sensor

Wireless Relay

Wireless CERV Controller

With the power of the CERV's wired and wireless inputs and outputs, the CERV can maximize your home's health and comfort through its Zone Configuration. Zone dampers installed in the ducting system can be linked to wired/wireless switches or other devices. If you're cooking in the kitchen, the CERV can prioritize kitchen ventilation. Showering? The CERV exhausts that humid bathroom air.

Zone Types

Supply

Exhaust

Active Close
